6-Passenger Panoramic Elevator

Car Size: 1100mm x 1000mm
Shaft Size: 1600mm x 1400mm
Door Opening: 800mm
Cabin Height: 2200mm

8-Passenger Panoramic Elevator

Car Size: 1200mm x 1100mm
Shaft Size: 1700mm x 1500mm
Door Opening: 900mm
Cabin Height: 2300mm

10-Passenger Panoramic Elevator

Car Size: 1300mm x 1200mm
Shaft Size: 1800mm x 1600mm
Door Opening: 1000mm
Cabin Height: 2400mm

13-Passenger Panoramic Elevator

Car Size: 1400mm x 1300mm
Shaft Size: 2000mm x 1700mm
Door Opening: 1100mm
Cabin Height: 2500mm

Rated Speed

0.5 m/s to 1.5 m/s

Load Capacity

450kg to 1000kg (6 to 13 passengers)

Drive System

• Gearless Traction Motor

• VVVF Inverter Controlled

• Ultra-Smooth, Noise-Free Operation

Control System

• Microprocessor-based Intelligent Controller

• Auto-Dispatch & Floor Leveling

• Touch Panel / Button Interface Options

Door Type

• Glass Automatic Sliding Doors

• Frameless or Stainless Steel Trim Options

• Panoramic Visibility with Full-Glass Panels

Safety Features

• Overload Detection

• Automatic Rescue Device (ARD)

• Emergency Intercom & Stop Switch

• Infrared Safety Curtain

• Anti-Skid Designer Flooring

Mobility

Precise cabin position tracking using high-accuracy magnetic or optical sensors for smooth vertical movement and floor alignment

Sensors

• Infrared Door Sensors (Curtain Sensor) for enhanced safety and smoother door operation

• Overload Sensor for real-time monitoring of load capacity

• Leveling Sensors to ensure precise floor leveling for easy entry and exit

• Top & Bottom Limit Switches for travel restriction and added safety

Control

• PLC/Microcontroller-based control system for high reliability and optimal performance

• Industrial-grade Push Buttons or Touch Display Panels with intuitive user interfaces

• Remote Monitoring via GSM/IoT for predictive maintenance and real-time diagnostics

Additional Options

• Voice Announcer and LED Floor Indicators for intuitive user interaction and convenience

• Automatic Rescue Device (ARD) in case of power failure to ensure continued operation

• Wi-Fi-based Service Diagnostics for effortless, fast maintenance and troubleshooting

Materials

• High-durability construction using premium mild steel, stainless steel, and aluminum composite panels for a sleek, modern aesthetic

• Powder-coated cabin and shaft components to ensure superior corrosion resistance and a long-lasting, attractive finish

Energy Efficiency

Power Consumption

• Operational Load: Typically 2–5 kW, depending on motor capacity and lift configuration

• Standby Mode: As low as 100W, enabled by energy-saving controllers for minimal power usage when not in operation

Voltage & Supply

• Main Drive: 3-phase, 400V AC, 50Hz for robust performance and consistent power delivery

• Control Circuit: 24V DC for safe, efficient, and stable operation of all control systems
